Siemens FDSB221

Mounting / Installation
Detector locking device FDBZ293
5
27
Building Technologies
A6V10320090_c_en_--
Fire Safety 02.11.2011
5.1 Detector locking device FDBZ293
Using a detector locking device FDBZ293, protects a FDSB221 or FDSB229
interbase against theft.
Detector locking device FDBZ293
1. Use the hexagonal wrench provided to insert the grub screw into the interbase
from the detector side by turning a few revolutions.
2. Screw the interbase into the detector base.
3. Screw the grub screw back in until it touches the detector base.
Another FDBZ293 detector locking device
can be used to protect the point detector fitted in the interbase against theft.
