Siemens FDSB221

Annex technical data
Tones and sound levels of the interbase (DC 32 V)
9
37
Building Technologies
A6V10320090_c_en_--
Fire Safety 02.11.2011
Tone No. 3: Sweep-down
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 78 73 80 79 74 77 78 76 80 80 74 77
Tone No. 4: Slow-whoop Sweep-up, linear
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 79 74 80 81 76 76 80 77 81 81 75 77
Tone No. 5: Pulse tone
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 69 76 77 72 72 74 71 76 76 69 73
Tone No. 6: Intermittent
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 74 69 75 76 72 71 73 71 76 76 67 72
Tone No. 7: Continuous
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 76 70 77 78 73 73 74 72 77 77 71 74
Tone No. 8: Alternating
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 70 77 76 71 73 75 72 76 76 70 74
Tone No. 9: Intermittent
Sound level Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 69 77 76 72 71 76 69 76 76 69 74
