Adjustment elements
8
31 | 34
Building Technologies
A6V10407862_d_en_
--
Siemens Industry, Inc.
2018
-
09
-
07
Rotary switch for device configuration
Configuration via the rotary switch is required for an Ethernet switch that is not
integrated into a panel. As an integrated Ethernet switch, the rotary switch must be
set to '0'.
By using the rotary switch for device configuration, the Ethernet switch can be set to
predefined network addresses or operation modes.
To accept a new configuration, the switch must be in a de-energized state when the
setting is made or a hardware reset must be performed afterward.
Switch position IP address/operating mode Sub-net mask/operating mode
0 Configured via web interface or MoNet
bus
Factory setting: 0.0.0.0
Configured via web interface or MoNet
bus
Factory setting: 255.255.248.0
1 192.168.99.241 255.255.248.0
2 192.168.99.242 255.255.248.0
3 192.168.99.243 255.255.248.0
4 192.168.99.244 255.255.248.0
5 192.168.99.245 255.255.248.0
6 192.168.99.246 255.255.248.0
7 192.168.99.247 255.255.248.0
8 192.168.99.248 255.255.248.0
9 192.168.99.249 255.255.248.0
A 192.168.99.250 255.255.248.0
B 192.168.99.251 255.255.248.0
C 192.168.99.252 255.255.248.0
D Reserved (0.0.0.0) Reserved (255.255.255.255)
E Repeater mode Repeater mode
F 192.168.200.4 255.255.255.0
