Siemens FT2001-A1 User Manual

2
Building Technologies
A6V10082691_j_en_
--
Fire Safety 2018-09-28
Features and Functions
FT2001 mimic display driver
● Can be connected via FDnet/C-NET
● Power supply via FDnet/C-NET
● Outputs are freely programmable
● 2x 24 outputs for controlling LEDs on mimic displays
● 3 outputs for expanded periphery
● 2 control outputs for local buzzer and LED operating status display
● 2 inputs for the 'Silence buzzer' and 'LED test' function buttons
● Integrated line separator
● External, electrically isolated AC/DC supply possible
● MC link connection socket for firmware update
F50F410 LED ribbon cable*
● For connection to the mimic display driver FT2001-A1
● 50-pin
● 24 red LEDs
● 1 m long
* must be ordered separately

Siemens FT2001-A1 Specifications

General

Brand	Siemens
Model	FT2001-A1
Category	Measuring Instruments
Language	English
