Fire Safety 2018-09-28
Technical data
FT2001-A1
FDnet/C-NET
Operating voltage DC 16…33 V
Max. operating current 45 mA
Max. quiescent current 5 mA
Max. capacitive load to ground C = 500 nF
Max. capacitive load to ground with
external supply
C = 100 nF
Supply
External supply input
● DC
14…32 V, electrically isolated,
EN54-4 conformity not required
● AC
11…22 V, electrically isolated,
EN54-4 conformity not required
Key figures
Address connection factor AK = 1
Quiescent current connection factor RK = 16
Maximum current connection factor:
● Without external supply:
– With 24 LEDs
– With 36 LEDs
– With 48 LEDs
MK = 52…80
MK = 68…130
MK = 80…165
● With external supply MK = max. 16
Outputs
Operation LED (X8; 'LED_1')
● Max. output current 2.5 mA constant at Usys (12 … 32 V)
Driver outputs (X11/X12)
● Max. output current with LED
operation
2.5 mA and DC 2.5 V
Buzzer (X5/5.6)
● Max. output current 5 mA and DC 12 V
Connections
LED signal outputs Plug-type connection with flat-ribbon cable
Connection terminal 0.08…1.5 mm
2
Ambient conditions
Operating temperature 0…40 °C
Storage temperature -20…+60 °C
Air humidity ≤95 % rel.
