en Appliance door
22
4. Loosen and remove the screws on the left and right
of the appliance door (figure #).
5. Before closing the door again, trap a tea towel which
has been folded several times in the door (figure $).
Pull out the front panel upwards and lay it on a flat
surface with the door handle facing downwards.
6. Push both retainers on the intermediate panel
upwards, but do not remove it (figure %). Hold the
panel with one hand. Remove the panel.
Clean the panels with glass cleaner and a soft cloth.
Fitting the door on the appliance
When fitting the intermediate panel, make sure that the
arrow is in the top right of the panel and that it aligns
with the arrow on the metal panel.
1. Insert the intermediate panel at the bottom into the
retainer and push it in firmly at the top (figure !).
2. Push both retainers downwards (figure ").
3. Insert the front panel at the bottom into the retainers
(figure #).
4. Close the front panel until both upper hooks are
opposite the opening (figure $).
5. Press the front panel at the bottom until it clicks
audibly into place (figure %).
6. Open the appliance door again slightly and remove
the tea towel.
7. Screw both screws back in on the left and right.
8. Put the cover back in place and press on it until it
clicks audibly into place (figure &).
9. Close the appliance door.
Caution!
Do not use the cooking compartment again until the
panels have been correctly fitted.
