GAMMA instabus
Technical Product Information
February 2013
IP Controller N350E 5WG1 350-1EB01
Technical manual N350E, 4 Seiten Siemens AG
Infrastructure & Cities Sector, Building Technologies
Update: http://www.siemens.com/gamma © Siemens AG 2013 Control Products and Systems
Subject to change without further notice P.O. Box 10 09 53, D-93009 Regensburg
2.12.1.12/2
Installation Instructions
· The device may be used for permanent interior instal-
lations in dry locations within distribution boards or
small casings with DIN rail EN 60715-TH35-7,5.
V
WARNING
· The device must be mounted and commissioned by an
authorised electrician.
· The device may be mounted to switch and socket
combination box mounts if VDE-certified devices are
used exclusively.
· The prevailing safety rules must be heeded.
· For planning and construction of electric installations,
the relevant guidelines, regulations and standards of
the respective country are to be considered.
Technical Specifications
Network communication
· Ethernet:
10BaseT (10 Mbit/s)
· Supported Internet Protocols:
ARP, ICMP, IGMP, UDP/IP, DHCP
· KNXnet/IP according to KNX System Specification:
Core, Device Management
Rated voltage
· Bus: DC 24V (DC 21...30V)
· Auxiliary power supply:
AC/DC 24V (AC/DC 12...30V)
Power supply
· Bus voltage: via KNX bus line
· Operating voltage:
from external SELV power supply AC/DC 24V nominal,
permissible input voltage range:
AC/DC 12 ... 30 V
· Recommended power supplies:
– DC 24V (before choke) from KNX power supplies
N125/x2
Control elements
· 1 learning button:
for switching between normal operating mode and
addressing mode
· 3 push buttons (Move, Prg/Set, ESC):
on the front side to locally set date and time and to
display IP address, MAC address and firmware version
of the device
Display elements
· 1 yellow LED: Ethernet Link Signal available (LK)
· 1 yellow LED: Data transmission on Ethernet (LA)
· 1 red LED: for monitoring bus voltage and displaying
mode, selected with the learning button
· LC-Display, 2 rows with 12 characters each to display
date and time
Connections
· bus line: screwless bus connection block (red-black)
0,6...0,8 mm Ø single core
· Ethernet / IP network: RJ45 socket
· auxiliary power:
screwless extra low voltage terminal (yellow-white)
Æ 0,6 ... 0,8 mm Ø single core
Physical specifications
· housing: plastic
· DIN-rail mounted device,
width: 2 SUs (1SU = 18mm), height: 55 mm
· installation: rapid mounting on EN 60715-TH35-7,5 rail
· weight: approx. 150g
Electrical safety
· degree of pollution (according to IEC 60664-1): 2
· protection (according to EN 60529): IP 20
· overvoltage class (according to IEC 60664-1): III
· bus: safety extra low voltage SELV DC 24 V
· the device complies with EN 50 090-2-2
Electromagnetic compatibility
complies with EN 50090-2-2
Environmental specifications
· climatic conditions: EN 50090-2-2
· ambient temperature operating: 0 ... + 45 °C
· storage temperature: - 25 ... + 70 ° C
· relative humidity (non-condensing): 5 % to 93 %
Markings
EIB, KNX, CE
CE mark
complies with the EMC regulations (residential and func-
tional buildings), and low voltage regulations
