Rails en
31
4.
Note:The lettering "Pyro" must be legible at the top,
as shown in the picture.
Slide the inner pane into the retainer at the bottom
and fit it at the top.
5.
Push the inner pane in at the top . Push the sliding
caps downwards in the direction of the arrow.
6.
Open the appliance door fully.
7.
Close the locking levers on the left- and right-hand
hinges
8.
Close the appliance door.
Note:Do not use the cooking compartment again until
the door panes have been correctly fitted.
Rails
23 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
23.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
▶ Never touch the shelf supports when hot.
▶ Always allow the appliance to cool down.
▶ Keep children at a safe distance.
1.
Lift the rail forwards slightly and detach it .
2.
Pull the whole rail to the front and remove it.
3.
Clean the rail.
→"Cleaning products", Page23
23.2 Attaching the rails
Notes
¡ The rails only fit on the right or left.
¡ For both rails, ensure that the curved rods are at the
front.
1.
First, push the rail into the middle of the rear
socket until the rail rests against the cooking
compartment wall, and then push this back .
2.
Push the rail into the front socket until the rail
also rests against the cooking compartment wall,
and then press this downwards .
