6/17
Building Technologies CC1N7106en
HVAC Products 20.02.2008
Standards and certificates
Conformity to EEC directives
- Electromagnetic compatibility EMC (immunity)
- Directive for gas-fired appliances
2004/108/EC
90/396/EEC
ISO 9001: 2000
Cert. 00739
ISO 14001: 2004
Cert. 38233
Identification code to EN 298
LME39.100…
F T C L B N
LME39.400…
A B C L B N
Disposal notes
The unit contains electrical and electronic components and must not be disposed of to-
gether with domestic waste.
Local and currently valid legislation must be observed.
Mechanical design
• The housing is made of impact-proof, heat-resistant and flame-retarding plastic. It is of
plug-in design and engages audibly in the base
• Burner controls LME39… and plug-in base AGK11.6 are silver-grey (RAL7001)
• The housing accommodates the
- microcontroller for the control sequence and the control relays for load control
- electronic flame signal amplifier (ionization)
- lockout reset button with its integrated 3-color signal lamp (LED) for operational
status and fault status messages and the socket for connecting the OCI400 inter-
face adapter
• The AZL2… display and operating unit is for direct connection to the burner control. All
safety-related digital inputs and outputs of the system are monitored by the contact
feedback network. Operation and parameterization of the LME39… is accomplished
with the AZL2… or via the OCI410… / ACS410
• Unlimited burner capacity (thermal output on startup ≤120 kW)
• 3 repetitions in the event of loss of flame during operation (can be parameterized)
• Multicolor indication of operational status and fault status messages
• Forwarding of operational status messages, fault status messages and full service
information via additional OCI400 / OCI410… interface adapter and Windows ACS410
PC software
RJ11 jack for connection of the AZL2… display and operating unit or the OCI410… inter-
face adapter for communication and parameterization via Windows ACS410 PC tool.
The most important time parameters for the program:
− Prepurge time (t1)
− Preignition time (t3)
− Postignition time (t3n)
− Interval (t4)
− Postpurge time 1 (t8-1)
− Opening time for actuators (t11)
− Closing time for actuators (t12)
Both the prepurge time and the safety times are safety-related and can be changed by the
OEM with the help of the display and operating unit.
LME39...
Indication and
diagnostics
Display and
communication
Time parameters
