LOGO! Manual
A5E00067781 01
204
LOGO! Power
12 V / 4.5 A
LOGO! Power
12 V / 1.9 A
Safety
Electrical isolation, primary/
secondary
Yes, SELV (to EN 60950/VDE 0805)
Safety class II (to IEC 536/VDE 0106 T1)
Type of protection IP 20 (to EN 60529/VDE 470 T1)
CE marking
UL/CSA certification
FM approval
Yes
Yes UL 508 / CSA 22.2
In preparation
General details
Ambient temperature range –20 ... +55°C, natural convection
Storage and transport tem-
perature
- 40 ... +70°C
Connections on input One connector (1x2.5mm
2
o. 2x 1.5 mm
2
)
each for L1 and N
Connections on output Two connectors (1x2.5mm
2
o. 2x 1.5 mm
2
)
each for L+ and M
Installation On 35 mm DIN rail, snap–on
Dimensions in mm (WxHxD) 72 x 80 x 55 126 x 90 x 55
Approx. weight 0.2 kg 0.4 kg
Technical Specifications
