Accessories
A.2 Antenna cable
LOGO! CMR2020, LOGO! CMR2040
Operating Instructions, 10/2016, C79000-G8976-C356-03
157
Figure A-4 GPS antenna, ANT895-6ML, flat antenna
6GK5895-6ML00-0AA0 Antenna ANT 895-6ML, active GPS antenna incl. connecting cable (0.3 m) and N
female connector; 20 dBi; IP67, -40 ... +85 °C, mounting using magnets or screws
Antenna cable
Antenna cable
Note
Maximum length of the antenna cable
The maximum permitted length of the antenna cable is 15 m.
Table A- 1 Antenna connecting cables
Flexible connecting cable preassembled SIMATIC NET N-Connect/SM male/male
6XV1875-5LH10 1 m
6XV1875-5LH50 5 m
Flexible connecting cable preassembled SIMATIC NET N-Connect/N-Connect
6XV1875-5AN10 10 m
