10/28
Building Technologies Division CC1N7785en
20.11.2017
Accessories (to be ordered separately) (cont‘d)
Gas burner controls, without plug-in base
For AC 230 V* Control sequence and
connection diagram like
Preferred use
LGK16.122A27* LFL1.122 Flash-steam generators
LGK16.133A27 LFL1.133 Flash-steam generators
LGK16.322A27* LFL1.322 Also suited for direct-fired
air heaters
LGK16.333A27* LFL1.333
LGK16.335A27* LFL1.335
LGK16.622A27* LFL1.622
LGK16.635A27* LFL1.635
* For burner controls operating on AC 100...110 V, 50...60 Hz, the last 2 digits of the
type reference read «17» in place of «27»
Connection accessories
for medium-capacity
burner controls
Plug-in base AGM17
Article no.: BPZ:AGM17
- with Pg11 thread for cable entry glands
Plug-in base AGM17.1
Article no.: BPZ:AGM17.1
- with M16 thread for cable entry glands
see Data Sheet N7230
Flame detectors Flame detectors QRA53.../QRA55...
see Data Sheet N7712
Ionization probe
to be supplied by thirds
