Type summary (cont’d)
The type references given below apply to the LGK16 without plug-in base and without
flame detector. For ordering information for plug-in bases and other accessories, see
Accessories.
For flame supervision with flame detector QRA53.../QRA55... or ionization probe
Preferred use:
Flash-steam
generators
Flash-steam
generators
Also suited for
direct-fired air
heaters)
Type
LGK16.122A27* LGK16.133A27 LGK16.322A27* LGK16.333A27* LGK16.335A27* LGK16.622A27* LGK16.635A27*
Article
no.
BPZ:LGK16.122A27 BPZ:LGK16.133A27 BPZ:LGK16.322A27 BPZ:LGK16.333A27 BPZ:LGK16.335A27 BPZ:LGK16.622A27 BPZ:LGK16.635A27
t1 10 s 9 s 35.5 s 31.5 s 37 s 65 s 66 s
TSA 2 s 3 s 2 s 3 s 2.5 s 2 s 2.5 s
TSA´ 2 s 3 s 2 s 3 s 5 s 2 s 5 s
t3 4 s 3 s 4 s 6 s 5 s 4 s 5 s
t3´ 4 s --- 4 s 6 s 2.5 s 4 s 2.5 s
t3n --- --- --- --- --- --- ---
t4 6 s 6 s 10 s 11.5 s 12.5 s 10 s 12.5 s
t4´ 6 s --- 10 s 11.5 s 15 s 10 s 15 s
t5 4 s 3 s 10 s 11.5 s 12.5 s 10 s 12.5 s
t6 10 s 14.5 s 12 s 17 s 15 s 12 s 15 s
t7 2 s 3 s 2 s 3 s 2.5 s 2 s 2.5 s
t8 30 s 29 s 65 s 69 s 74 s 95 s 103 s
t9 2 s 3 s 2 s 3 s 5 s 2 s 5 s
t10 6 s 6 s 8 s 11.5 s 10 s 8 s 10 s
t11 Optional
t12 Optional
t13 10 s 14.5 s 12 s 17 s 15 s 12 s 15 s
t16 4 s 3 s 4 s 6 s 5 s 4 s 5 s
t20 32 s 60 s --- 26 s 22 s --- ---
