Page #13 background imageLoading...
Page #13 background image
Mounting and installation
2
Wired compo
nents
13
Siemens Operator / Room / Auxiliary devices CE1U2358en_04
Building Technologies 2014-09-26
Terminal Designation QAA75.610 QAA75.611
1 CL+ BSB data BSB data
2 CL- BSB ground BSB ground
3 G+ Reserved Power supply DC 12 V
Connections
Dimensions and drilling
plan
