3.3.4 Overview of the settings
The table displays all available settings.
E End-user F heating engineer BZ Operating line
Operating line
Operating line clear-text units
User level
Function Default value Min max Unit
Time of day and date
50 1 E Hours/minutes 01:00 00:00 23:59 hh:mm
51 2 E Day / month 1.01 01.01 31.12 dd.mm
52 3 E Year 2004 2004 2099 yyyy
53 4 F Start of summertime 25.03 01.01 31.12 dd.mm
54 5 F End of summertime 25.10 01.01 31.12 dd.mm
59 6220 F software version - 0 99.9 -
Time prog heating circuit 1
60 500 E Preselection Mo - Su -
61 501 E 1. Phase on 6:00 00:00 24:00 hh:mm
62 502 E 1. phase off 22:00 00:00 24:00 hh:mm
63 503 E 2. Phase on --:-- 00:00 24:00 hh:mm
64 504 E 2. phase off --:-- 00:00 24:00 hh:mm
65 505 E 3. Phase on --:-- 00:00 24:00 hh:mm
66 506 E 3. phase off --:-- 00:00 24:00 hh:mm
Time prog heating circuit 2
67 520 E Preselection Mo - Su
68 521 E 1. Phase on 6:00 00:00 24:00 hh:mm
69 522 E 1. phase off 22:00 00:00 24:00 hh:mm
70 523 E 2. Phase on --:-- 00:00 24:00 hh:mm
71 524 E 2. phase off --:-- 00:00 24:00 hh:mm
72 525 E 3. Phase on --:-- 00:00 24:00 hh:mm
73 526 E 3. phase off --:-- 00:00 24:00 hh:mm
Time program for DHW
74 560 E Preselection Mo - Su
75 561 E 1. Phase on 6:00 00:00 24:00 hh:mm
76 562 E 1. phase off 22:00 00:00 24:00 hh:mm
77 563 E 2. Phase on --:-- 00:00 24:00 hh:mm
78 564 E 2. phase off --:-- 00:00 24:00 hh:mm
79 565 E 3. Phase on --:-- 00:00 24:00 hh:mm
80 566 E 3. phase off --:-- 00:00 24:00 hh:mm
Heating circuit 1
81 712 E Reduced setpoint HC1. 16 4 35 °C
82 720 E Heating curve slope HC1. 1.5 0.10 4.00 °C
83 721 F Heating curve displacement HC1. 0 -4.5 4.5 °C
84 730 E Summer/winter heating limit HC1. 18 - - - / 8 30 °C
85 741 F Flow temperature setpoint maximum HC1. 80 8 95 °C
Heating circuit 2
