Table 2: Terminal torque values
Sr.
No.
Type Size
Torque
(Nm)
1 Terminalblock30A M4 0.8–1.4
2 Terminalblock60A M5 1.5–2.1
3 Terminalblock100A M6 2.5–3.0
4 DualVAMeter200A–Current
terminals
M4 1.2
5 DualVAMeter30A–Current
terminals
M4 1.2
6 DualVAMeter60A–Current
terminals
M6 2.5
7 DualVAMeter100A–Current
terminals
M8 5.0
8 CT200/5A M3.5 0.9
9 PowerLink M6 4–6
10 SelectorSwitch3LD4 M3 0.5
11 Multiwaystrips M3 0.4–0.6
12 Indicatinglight–Amber/Green M3 0.8–0.9
NOTE:ContactsalesforON&OFFPushButton,Terminalblock30A/60A/100A,DualVAmeter,Doorknob,Rockerswitch,
Currenttransformer(200/5A).
FormoreTechnicaldetailslikeLMR-Awiring,operatingsequence,mountingdetailsetc.,
referInstallation&Troubleshootingguideno.A5E50797230A.
Sr.
No.
Description Order No.
21 Contactor 3TS3210-0AZ6-08K
22 ThermalOverloadRelay 3UW5102-1J
23 ThermalOverloadRelay 3UW5102-1K
24 ThermalOverloadRelay 3UW5202-2A
25 ThermalOverloadRelay 3UW5202-2B
26 ThermalOverloadRelay 3US5600-2C8K
27 ThermalOverloadRelay 3US5600-2D8K
28 ThermalOverloadRelay 3US5600-2R8K
29 ThermalOverloadRelay 3US5600-8M8K
30 ThermalOverloadRelay 3US5800-2T8K
31 ThermalOverloadRelay 3US5800-2P8K
32 ThermalOverloadRelay 3US5800-5C8K
33 Coilfor415V(3TS35/36) 3TY7443-0AR0
34 Coilfor380V(3TS35/36) 3TY7443-0AQ0
35 Coilfor200-400V 3TY7403-0AZ6
36 Coilfor260-460V(Z8) 3TY7403-0AW415
37 Coilfor415V(3TS47/48) 3TY7463-0AR0
38 Coilfor380V(3TS47/48) 3TY7463-0AQ0
39 Coilfor415V(3TS51) 3TY7503-0AR0
40 Coilfor380V(3TS51) 3TY7503-0AQ0
41 1NOContactBlock 3SB5420-0B
42 1NCContactBlock 3SB5420-0C
43 GreenLED 3SB5285-6HE06
44 AmberLED 3SB5285-6HL33
45 LMRAfor200-400V 7UG0613-0FE20
46 LMRAfor260-460V 7UG0613-0FF20
47 LMRAfor380V 7UG0613-0FG20
48 LMRAfor415V 7UG0613-0FH20
49 Timer 3RP1576-1NM208K
50 Timer 3RP1576-1NP208K
51 Addonblock 3TX4010-2A
52 Addonblock 3TX4001-2A
53 Addonblock 3TY7561-1KA00-08K
54 Addonblock 3TY7561-1AA00-08K
55 Phaseselectorswitch 3LD4001-4DC30-0RC0
Table 3: Spares list
Sr.
No.
Description Order No.
1 Contactor 3TS3210-0AZ6-08K
2 Contactor 3TS3110-0AZ6-08K
3 Contactor 3TS3010-0AZ6-08K
4 Contactor 3TS3210-0AZ8-08K
5 Contactor 3TS3010-0AZ8-08K
6 Contactor 3TS3300-0AZ6-08K
7 Contactor 3TS3300-0AZ8-08K
8 Contactor 3TS3110-0AZ8-08K
9 Contactor 3TS3500-0AZ8-08K
10 Contactor 3TS4722-0AR0-08K
11 Contactor 3TS3500-0AR0-08K
12 Contactor 3TS3600-0AR0-08K
13 Contactor 3TS4722-0AQ0-08K
14 Contactor 3TS3500-0AQ0-08K
15 Contactor 3TS4822-0AQ0-08K
16 Contactor 3TS3600-0AQ0-08K
17 Contactor 3TS5122-0AR0-08K
18 Contactor 3TS4822-0AR0-08K
19 Contactor 3TS3400-0AZ8-08K
20 Contactor 3TS5122-0AQ0-08K
