Siemens RAJA+ 3TE7421 - Dimensional Drawings and Disposal; Dimensional Drawings; Disposal Information

Fig. 10: Dimensional Drawing
Representative view for FASD1, 2
Siemens Limited
OrderNo.A5E50494782000A/AA
Productdevelopmentisacontinuousprocess.Consequently
thedataindicatedinthisLeaetissubjecttochangewithout
priornotice.Forlatestissuecontactoursalesofces.
SACHINENTERPRISE
Disposal
Siemensproductsareenvironmentfriendly,which
predominantlyconsistofrecyclablematerials.
Fordisposalswerecommenddisassemblingandseparation
intofollowingmaterials:
METALS:SegregateintoFerroustypesforrecyclingthrough
authorizeddealer.
PLASTICS:Segregateaspermaterialtypeforrecycling
throughauthorizeddealer.Becauseofthelonglifetimeof
SiemensProductsthedisposalguidelinesmaybereplaced
byothernationalregulationswhentakingtheproductout
ofservice.Thelocalcustomercareserviceisavailableatany
timetoanswerdisposal-relatedquestions.
CustomerCareTollfreeno.1800220987 Email:ics.india@siemens.com
Representative view for FASD3
A B C D E F G H J K øL
FASD1 370 475 179.5 390 405 45 101 94 84 410 7
FASD2 510 660 185.7 550 565 49.2 178.5 111 115 580 12
FASD3 580 740 205.7 620 620 55 99.5 229.2 156.2 650 12
S17891
L
Alternatemountingdimension
(Holeø7mm)
FASD1:284x400
FASD2:420x567
FASD3:490x647
M5earthingscrew(2x)
atbottomonbothsides
