Change of batteries If the battery symbol appears, the battery power is almost exhausted and the batteries
should be replaced.
To make a reset, first press and hold the
button, then press the 2 buttons
+
-
simulta-
neously for 3 seconds. All individual settings will be reset to their standard values.
Reset
Technical data
Operating voltage DC 3 V (2 x 1.5 V AA Alkaline batteries)
Battery life (RDE10.1DHW) > 1 year (AA Alkaline batteries)
Power supply
Heating valve or wall-hung boiler – Y1
Control output Q12 (NC contact)
Rating RDE0.1DHW (AC 24...250 V) max. 5(2) A
Control output Q14 (NO contact)
Rating RDE10.1DHW (AC 24...250 V) max. 5(2) A
Control outputs
DHW control – Y2
Control output Q22 (NC contact)
Rating RDE10.1DHW (AC 24...250 V) max. 5(2) A
Control output Q24 (NO contact)
Rating RDE10.1DHW (AC 24...250 V) max. 5(2) A
Switching differential SD 1 K
Setpoint setting range
Normal operation 5…35 °C
Energy saving 0 (OFF) and 5…35 °C
Factory setting normal operation 20 °C
Factory setting energy saving 8 °C
Frost protection 5 °C (fixed)
Resolution of settings and displays
Setpoints 0.5 °C
Switching times 60 min
Actual temperature value displays 0.5 °C
Time of day displays 1 min
Operational data
Operation to IEC 721-3-3
Climatic conditions class 3K5
Temperature 0…+50 °C
Humidity <95 % r.h.
Transport to IEC 721-3-2
Climatic conditions class 2K3
Temperature -25…+60 °C
Humidity <95 % r. h.
Mechanical conditions class 2M2
Environmental conditions
Storage to IEC 721-3-1
Climatic conditions class 1K3
Temperature -25…+60 °C
Humidity <95 % r. h.
conformity to
EMC directive 89/336/EEC
Low-voltage directive 73/23/EEC and 93/68/EEC
N474
C-Tick conformity to
EMC emission standard
AS/NSZ 4251.1:1994
Product standards
Automatic electrical controls for EN 60 730 – 1 and
household and similar use EN 60 730–2-9
Electromagnetic compatibility
Emissions EN 61 000–6-3
Immunity EN 61 000–6-1
Standards
6/8
Building Technologies Room temperature controller RDE10.1DHW CE1N3038en
HVAC Products 20.10.2005
