Siemens RDF300…/RDF340 / RDF400… / RDF600... Flush-mounted Room thermostats CE1N3076en
Building Technologies 2018-12-27
Type summary
Product
number
Stock number Features
Operating Voltage
Control outputs
Time program Backlit LCD Infrared receiver
1)
Suitable conduit box
2)
on/off 3pt DC 0..10V
RDF300 RDF300 AC 230 V
ü ü
square
RDF300.02 RDF300.02 AC 230 V
ü ü ü
square
RDF400.01 RDF400.01 AC 230 V
ü ü ü ü ü
square
RDF340 RDF340 AC 24 V
ü
square
RDF600 S55770-T291 AC 230 V
ü ü ü
round
RDF600T S55770-T292 AC 230 V
ü ü ü ü ü
round
1) Infrared remote control is to be ordered as separate item
2) Square conduit box e.g. ARG71.
Round conduit box min 60 mm diameter and min 40 mm depth
Ordering
· When ordering, indicate both product number / SSN number and name:
E.g. RDF600 / S55770-T291 room thermostat
· Order the IRA211 (S55770-T166) infrared remote control separately (for
RDF400../RDF600...).
· Order valve actuators separately.
Equipment combinations
Designation Product no. Data Sheet
*)
Cable temperature sensor or
changeover sensor, cable length
2.5 m
NTC (3 kW at 25 °C)
QAH11.1 1840
Room temperature sensor
NTC (3 kW at 25 °C)
QAA32 1747
Cable temperature sensor,
cable length 4 m
NTC (3 kW at 25 °C)
QAP1030/UFH 1854
Condensation monitor QXA21.. A6V10741072
Electromotoric ON/OFF actuator SFA21... 4863
Electromotoric ON/OFF valve and
actuator (only available in AP, UAE,
SA and IN)
MVI…/MXI… A6V11251892
Zone valve actuators (only available
in AP, UAE, SA and IN)
SUA… 4832
Thermal actuator (for radiator valve) STA23... 4884
Thermal actuator
(for small valves 2.5 mm)
STP23... 4884
On / off actuators
