Siemens RDG100…/RDG110…/RDG140.../RDG160… Basic Documentation CE1P3076.en
Building Technologies About this document 28 May 2009
1 About this document
1.1 Revision history
Edition Date Changes Section Pages
1.0 May 2009 First edition
1.2 Reference documents
Ref. Document title Type of document Document no.
[1] Wall-mounted room thermostats with LCD Data Sheet CE1N3181en
[2] RDG1… Operating Instructions CE1B3181.1en
[3] RDG100T Operating Instructions CE1B3181.2en
[4] RDG100, RDG100T Mounting Instructions CE1M3181.1en
[5] RDG110 Mounting Instructions CE1M3181.2en
[6] RDG140, RDG160 Mounting Instructions CE1M3181.3en
1.3 Before you start
1.3.1 Copyright
This document may be duplicated and distributed only with the express permission
of Siemens, and may be passed only to authorized persons or companies with the
required technical knowledge.
1.3.2 Quality assurance
The document was prepared with great care.
• The contents of the document is checked at regular intervals
• Any corrections necessary are included in subsequent versions
• Documents are automatically amended as a consequence of modifications and
corrections to the products described
Please make sure that you are aware of the latest document revision date.
If you find lack of clarity while using this document, or if you have any criticisms or
suggestions, please contact the Product Manager in your nearest branch office.
The addresses of the Siemens Regional Companies are available at
www.buildingtechnologies.siemens.com
.
.
Heronhill - for all your Siemens requirements
Tel: 01823 665660
www.heronhill.co.uk
Fax: 01823 665807

Siemens RDG100 Specifications

General

Power Supply	AC 230 V
Control Type	PI
Display	LCD
Output	Relay
Protection Class	IP30
Operating Voltage	AC 230 V
Type	Room thermostat
Temperature Setting Accuracy	±0.5 °C
Setpoint Setting Range	5 to 35 °C
Mounting	Wall
Weight	150 g
