16/23
Siemens RDG1... Wall-mounted room thermostats with LCD CE1N3181en
Building Technologies 2017-11-20
Based on EU Regulation 813/2013 (Eco design directive) and 811/2013(Labelling
directive) concerning space heaters, combination heaters ,the following classes apply:
RDG160T:
Application with On / Off operation of a heater Class I value 1.0%
Modulating room thermostat, for use with Class V value 3.0%
modulating heaters
Switching differential, adjustable
Heating mode (P30)
Cooling mode (P31)
2 K (0.5…6 K)
4 °F (1...12 °F)
1 K (0.5…6 K)
2 °F (1...12 °F)
Setpoint setting and setpoint range
Comfort mode (P08)
Economy mode (P11-P12)
Protection (P65-P66)
21 °C (5…40 °C)
70 °F (41...104 °F)
15 °C (59 °F)/30 °C (86 °F)
(OFF, 5...40 °C (41...104 °F)
8 °C (46 °F)/OFF
OFF, 5...40 °C (41...104 °F)
Multifunctional inputs X1/X2/D1
Input X1
Input X2
Input D1
Selectable
Ext. temperature sensor
(P38=1)
Changeover sensor
(P40=2)
Operating mode switchover
(P42=3)
Built-in room temperature sensor
Measuring range
Accuracy at 25 °C (77 °F)
Temperature calibration range
0…49 °C (32…120 °F)
< ± 0.5 K (± 1 °F)
± 3.0 K (± 6 °F)
Settings and display resolution
Setpoints
Current temperature value displayed
0.5 °C (1 °F)
0.5 °C (1 °F)
Operation
Climatic conditions
Temperature
Humidity
60721-3-3
Class 3K5
0…50 °C (32…122 °F)
<95% r.h.
Transport
Climatic conditions
Temperature
Humidity
Mechanical conditions
60721-3-2
Class 2K3
,25…65 °C (, 13…149 °F)
<95% r.h.
Class 2M2
Storage
Climatic conditions
Temperature
Humidity
60721-3-1
Class 1K3
,25…65 °C (, 13…149 °F)
<95% r.h.
EU Conformity (CE)
Electronic control type
CE1T3181xx
*)
2.B (micro-disconnection on
operation)
RCM Conformity
CE1T3181en_C1
*)
UL (RDG110U/RDG160TU)
UL 916 PAZX
CSA-C22.2 No. 205 PAZX7
http://database.ul.com
Safety class RDG160T
RDG160TU
II as per EN60730
III as per EN60730
Pollution class Normal
Eco design and
labelling directives
Operational data,
all types
Environmental
conditions
Standards and directives
