Siemens RDG110 Operating

6/12
Siemens RDG1... room thermostats N3181en
Building Technologies May 28. 2009
1
2
4
5
6
7
8
8
9
10
11
12 13
14
15
16
17
1819
20
2123
3
22
24
# Symbol Description # Symbol Description
1
Heating mode
14
Automatic fan
2
Heating mode
auxiliary heater on (2
nd
stage)
15
Manual fan
3
Cooling mode
Fan speed 1
4
Comfort mode Fan speed 2
5
Energy Saving mode
16
Fan speed
Fan speed 3
6
Auto Timer mode
7
View and set Auto Timer program
17
Degrees Celsius
Degrees Fahrenheit
8
Protection 18 Digits for room temperature and setpoint display
9
Escape
19 Button lock
10
Digits for time, room temperature,
setpoint, etc.
20
Condensation in room (dewpoint sensor active)
11
Setting the time of day and the
weekday
21 Weekday 1…7: 1 = Monday / 7 = Sunday
22 Fault
12
Morning: 12-hour format
Afternoon: 12-hour format
23
Temporary timer function (visible when
operating mode is temporarily extended due to
prolonged presence or absence)
13
Confirmation of parameters
24
Indicates that room temperature is displayed
Display
