SIEMENS
SWITCH LIVE TERMINAL
(To Boiler, Pump or Valve)
SEE NOTE BELOW
RDH10.1 & RDJ10.1, BATTERY POWERED UNITS
NOTE. LX, L1 & L2, ARE ‘VOLTS FREE,’ CONTACTS.
LX L1 L2
RDH10.1 & RDJ10.1
BACK PLATE
SATISFIED
TERMINAL
(Not Normally Used)
COMMON
TERMINAL
(Live Input)

Other manuals for Siemens RDH10RF

Preview: User Guide
User Guide15 pages
Preview: Mounting And Siting Notes
Mounting And Siting Notes5 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens RDH10RF and is the answer not in the manual?

Siemens RDH10RF Specifications

General IconGeneral
MountingWall-mounted
WirelessYes
DisplayLCD
Frost ProtectionYes
Power SupplyBattery
Set Temperature Range5°C to 30°C
Switching Voltage230V AC
Wireless Range30m
