Siemens RUGGEDCOM RSG2200 User Manual

Technical Specifications
5.6Operating Environment
Tx (dBm)
c
Mode Connec-
tor Type
Cable
Type
(µm)
a
Tx λ
(nm)
b
Minimum Maximum
Rx Sen-
sitivity
(dBm)
c
Rx Sat-
uration
(dBm)
c
Distance
(km)
d
Pow-
er Bud-
get (dB)
SM
e
SC 9/125 1550 0 5 -23 -3 70 23
a
All cabling is duplex type unless specified otherwise.
b
Typical.
c
All optical power numbers are listed as dBm averages.
d
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of
patches and splices. Consult a Siemens sales associates when determining maximum segment distances.
e
Operating temperature range of -20 to 85 °C (-4 to 185 °F) .
5.6 Operating Environment
The RUGGEDCOM RSG2100 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
a b
-40 to 85°C (-40 to 185 °F)
Ambient Storage Tem-
perature
-40 to 85°C (-40 to 185 °F)
Ambient Relative Hu-
midity
c
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing
5.7 Mechanical Specifications
Weight 5.2 kg (11.5 lbs)
Ingress Protection IP20
Enclosure 18 AWG Galvanized Steel
5.8 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Note
Dimensional tolerances are in accordance with ISO 2768-mK, unless otherwise stat-
ed.
RUGGEDCOM RSG2100
Installation Manual, 03/2020, C79000-G8976-1040-17
35
