VPN tunnel between SCALANCE M-800 and security CPs
4.2 Secure VPN tunnel with PSK
SCALANCE M-800 Getting Started
158 Getting Started, 06/2015, C79000-G8976-C337-04
4. For the configuration example, configure the VPN remote end with the following settings:
Remote Address 91.19.6.84/32
WAN IP address of the DSL router
5. Click "Set Values".
Configuring a VPN connection
Requirement
● The VPN remote end has been created.
1. Click on "Security" > "IPSec VPN" in the navigation area and on the "Connection" tab in
the content area.
2. In "Connection Name" enter a name for the VPN connection.
3. Click "Create". A new row is created in the table.
