Siemens SCALANCE M874-2 User Manual

Approvals
A.1 EU declaration of conformity
SCALANCE M874, M876
Operating Instructions, 06/2015, C79000-G8976-C331-05
69
A.1.4
Products
Product designation and standards
The standards that apply to the product are described in R&TTE (Page 66) and RoHS
(Page 68).
Product name
Standards
SCALANCE M874-2
3, 5, 6, 7, 15, 18
SCALANCE M874-3
3, 5, 6, 7, 8, 15, 16, 17, 19
SCALANCE M876-3
3, 5, 6, 7, 8, 15, 16, 17, 19
SCALANCE M876-4
3, 5, 6, 7, 8, 15, 16, 17, 18, 19
Maximum antenna gain
Users and installers must be provided with antenna installation instructions and transmitter
operating conditions that must be followed to avoid exceeding the permitted RF exposure.
Maximum antenna gain
GSM 1800
GSM 900
SCALANCE M874-2
10.04 dBi
4.05 dBi
SCALANCE M874-3
9.36 dBi
2.91 dBi
SCALANCE M876-3
9.36 dBi
2.91 dBi
Antenna gain for M876-4
Note
Depending on the selected wireless standard and the wireless frequency used, antennas
with different antenna gains can be used. If you change the frequency band during
operation, it is possible that the maximum permitted antenna again also changes. Check
w
hether the antenna you are using is approved for the changed frequency range. If
necessary, change the antenna so as not to violate the operational requirements. Or use an
antenna with a gain less than 3.58 dBi to cover all bands.
Frequency band
Maximum antenna gain in dBi
GSM /GPRS 900
3.58
E-GPRS 900
9.88
GSM /GPRS 1800
9.84
E-GPRS 1800
13.85
UMTS FDD1
13.35
UMTS FDD III
13.45
UMTS VIII
10.27
LTE FDD 3 12.66
LTE FDD 7
13.86
LTE FDD 8 10.58
LTE FDD 20
8.76
