Siemens SCALANCE W734-1 RJ-45

Technical data
9.1 SCALANCE W774/W734 RJ45
SCALANCE W774-1 / W734-1
68 Operating Instructions, 03/2022, C79000-G8976-C325-15
Technical specifications
Permitted cable lengths
(Ethernet)
(Alternative combinations per length range)
IE TP torsion cable
0 ... 55 m
0 ... 45 m + 10 m TP cord
IE FC TP marine cable
IE FC TP trailing cable
IE FC TP flexible cable
IE FC TP FRNC cable
IE FC TP festoon cable
IE FC TP food cable
0 ... 85 m
0 ... 75 m + 10 m TP cord
IE FC TP standard cable
0 ... 100 m
0 ... 90 m + 10 m TP cord
Wireless interface
Antenna connector
Quantity
2
Design
R-SMA female
Impedance
50 Ω nominal
Frequency range
2412 ... 2480 MHz
4920 ... 5875 MHz
Electrical data
Direct 24 VDC supply
Supply voltage from terminal block
24 V DC safety extra low voltage (SELV)
Permitted range
19.2 to 28.8 VDC
Design
Terminal block, 4 terminals
Properties
Electrically isolated, redundant design
PoE to 24 VDC non-redundant design
Supply voltage from PoE
Supply voltage
48 VDC
Permitted range
36 to 57 VDC
Fusing
2 A / 24 VDC
1 A / 48 V DC PoE
Current consumption
At 24 VDC / typical
250 mA
With PoE / typical
125 mA
Power loss at 24 VDC
At 24 VDC / typical
6 W
With PoE / typical
6 W
Permitted ambient conditions
Ambient temperature
During operation with the rack
installed horizontally / vertically
-20 ℃ to +60 ℃
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation
≤ 95% at 25 °C, no condensation
Operating altitude
During operation
≤ 2,000 m above sea level at max. 60 °C
ambient temperature
Contaminant concentration
According to IEC 60721
Degree of protection
IP code
IP30
