Installation and removal
5.3 Wall mounting
SCALANCE W778-1 / W738-1
Operating Instructions, 03/2022, C79000-G8976-C450-07
41
5.3 Wall mounting
Note
Depending on the mounting surface, use suitable fittings.
Note
The wall mounting must be capable of supporting at least four times the weight of the
device.
To mount the device on a wall, follow the steps below:
1. Prepare the drill holes for wall mounting. For the precise dimensions, refer to the
section "Dimension drawing (Page 73)".
2. Secure the device to the wall with four screws. The screws are not supplied with the
device.
3. Connect the power supply, refer to the section "Power supply (Page 54)".
4. Fit the antennas, refer to the section "Antennas (Page 57)".
