Connecting up
6.4 Suitable antenna cables and antennas
SCALANCE W788-x / W748-1
Operating Instructions, 06/2016, A5E03678333-10
37
Connecting cable IWLAN QMA/N-Connect male/female
Flexible adapter cable of antennas with QMA socket for antenna connecting cable. pack of 3
Length
Order number
1 m
6XV1875-5JH10
For railway applications, the following cables are available: Scope of delivery: Pack of 1
Length
Order number
1 m
6XV1875-5VH10
Suitable antennas
Note
When you select an antenna, keep in mind the national approvals for your SCALANCE
W786.
The model SCALANCE W786-2IA RJ-45 uses internal omni antennas (3/4 dBi at 2.4 GHz or
5 GHz). For the other SCALANCE W786 models, the following antennas have been
approved:
Type
Properties
Order number
ANT792-4DN RCoax helical antenna, circular
polarization, 4 dBi, 2.4 GHz, N-
Connect female.
6GK5 792-4DN00-0AA6
ANT792-6MN Omni antenna, mast/wall mounting,
6 dBi 2.4 GHz, N-Connect female
6GK5 792-6MN00-0AA6
ANT792-8DN Directional antenna, mast/wall
mounting, 14 dBi 2.4 GHz, N-
Connect female
6GK5 792-8DN00-0AA6
ANT793-4MN RCoax λ5/8 antenna with vertical
polarization, 6 dBi, 5 GHz, N-
Connect female.
6GK5 793-4MN00-0AA6
ANT793-6DG Wide angle antenna, mast/wall
mounting, 9 dBi 5 GHz, 2 x N-
Connect female
6GK5 793-6DG00-0AA0
ANT793-6DT Wide angle antenna (MIMO),
mast/wall mounting, 8 dBi 5 GHz, 3
x QMA connector female
6GK5 793-6DT00-0AA0
ANT793-6MN Omni antenna, mast/wall mounting,
5 dBi 5 GHz, N-Connect female
6GK5 793-6MN00-0AA6
ANT793-8DJ Directional antenna, mast/wall
mounting, 18 dBi 5 GHz, 2 x N-
Connect female
6GK5 793-8DJ00-0AA0
ANT793-8DK Directional antenna, mast/wall
mounting, 23 dBi 5 GHz, 2 x N-
Connect female
6GK5 793-8DK00-0AA0
