Siemens SCALANCE W788-1 User Manual

Connecting up
6.4 Suitable antenna cables and antennas
SCALANCE W788-x / W748-1
36 Operating Instructions, 06/2016, A5E03678333-10
6.4
Suitable antenna cables and antennas
N-Connect/R-SMA connecting cable for RJ-45
The N-Connect/R-SMA male/male flexible connecting cable is available as an accessory for
connecting to a SCALANCE W700 with R-SMA connectors.
Length
Order number
0.3 m
6XV1875-5CE30
1 m 6XV1875-5CH10
2 m
6XV1875-5CH20
5 m
6XV1875-5CH50
10 m
6XV1875-5CN10
For railway applications, the following cables are available:
Length
Order number
1 m 6XV1875-5TH10
2 m
6XV1875-5TH20
5 m
6XV1875-5TH50
N-Connect / N-Connect connecting cable
To connect a SCALANCE W700 M12 with N-Connect e.g. for a connection with a lightning
protection element LP798-1N/LP798-2N or also for connection to the cabinet feedthrough or
for connecting QMA antennas to M12 (with an additional adapter cable) the
N-Connect/N-Connect Male/Male Flexible Connection Cable is available as an accessory.
Length
Order number
1 m
6XV1875-5AH10
2 m
6XV1875-5AH20
5 m
6XV1875-5AH50
10 m
6XV1875-5AN10
For railway applications, the following cables are available:
Length
Order number
1 m
6XV1875-5SH10
2 m
6XV1875-5SH20
5 m
6XV1875-5SH50
