Product Characteristics
4.3 SCALANCE X101-1FL
Note
The link state of port P1 and port P2 (LED lit green) in stand-alone-mode is only indicated if
both ports have link at the same time.
Transparent link display (green LED)
“TL” (transparent link) LED:
The TL LED has no function.
Status Meaning
Not lit Stand-alone mode. DTEs are connected to both ports of the
media converter (no cascading)
A direct cascade connection of two SCALANCE X101-1FL media converters is not possible,
thus no transparent link.
Industrial Ethernet Media Converters SCALANCE X-100 Series
4-22 Commissioning Manual, 07/2008, A2B00051521A
