Instrument transformers
Figure 5: Type SDV6 distribution circuit breaker with interphase barriers and bushing current transformers installed in primary compartment
Load side
2-4-6
Load side
1-3-5
Insulation plates apply only in 27.6 kV and 38.0 kV
Operator compartment
Low-voltage compartment
High-voltage compartment
Bushing current transformer
(one per bushing shown)
17
