Compact Operating Instructions
1.9 Commissioning
SIMATIC HMI IPC477C / HMI IPC477C PRO
Compact Operating Instructions, 10/2010, A5E02368072-02
23
1.9.2 Basic commissioning - initial startup
Requirement
● The device is connected to the 24 VDC power supply.
● The ground conductor is wired.
● The cables are correctly plugged in.
Setting up the operating system
Note
Initial commissioning of Windows Embedded Standard
System startup can take longer than usual for the initial commissioning. Only a blue screen
is displayed for several minutes.
The devices with touch panel require a USB mouse or USB keyboard for commissioning.
During the initial startup of the computer, the operating system that is preinstalled on the
Compact Flash card or Solid State Drive (SSD) is set up automatically.
Proceed as follows:
1. Switch the device on using the On/Off switch. The device now performs an power-on self
test. During the self-test, this message appears:
Press <F2> to enter SETUP or <ESC> to display the Boot menu
2. Wait until this message is cleared, then follow the instructions on the screen.
NOTICE
The device may not be switched off at any time during the installation process.
Do not change the default BIOS settings, otherwise the operating system setup may
become corrupted.
3. Restart
After you have entered all the necessary information and the operating system is
configured,
you are prompted to restart the system. Acknowledge this prompt with Yes.
Note
System startup can take longer than usual for the initial commissioning. The screen
display "FBResseal Resealing in progress..." is shown for several minutes.
Note
Errors and warnings can be displayed in the status bar, with the first and second switch
on of the initial commissioning or after a restore procedure This will have no effect on the
device functions.
