Siemens SIMATIC HMI IPC477C User Manual

Compact Operating Instructions
1.5 Accessories
SIMATIC HMI IPC477C / HMI IPC477C PRO
8 Compact Operating Instructions, 10/2010, A5E02368072-02
1.5 Accessories
These accessories are not included in the product package.
Accessories Order no.
2 GB Compact Flash card 6ES7648 - 2BF02 - 0XF0
4 GB Compact Flash card 6ES7648 - 2BF02 - 0XG0
8 GB Compact Flash card 6ES7648 - 2BF02 - 0XH0
1 GB DDR3 memory module 6ES7648 - 2AH40 - 0AH0
2 GB DDR3 memory module 6ES7648 - 2AH50 - 0AH0
4 GB DDR3 memory module 6ES7648 - 2AH60 - 0AH0
Touch pen 6AV7672 - 1JB00 - 0AA0
Note
Replace Compact Flash cards only with cards of the same product versions
Only SIMATIC PC Compact Flash cards with product version number 02 (ES 02 or higher)
can be used for this device.
1.6 Affixing Labeling Strips for Function Keys and Softkeys
Note
The following table applies only to devices with a key panel.
The control unit has two horizontal and two vertical keypads for the function keys and the
softkeys. Assign user specific functions to the keys as needed. You can mark these keys
with labeling strips. A4 films for creating the labeling strips are available as accessories.
Proceed as follows to affix the labeling strips:
