Siemens SIMATIC NET CP 5711 User Manual

CP 5711
Operating Instructions, 12/2021, C79000-G8976-C283-08
29
Technical specifications
5
Technical specifications of the CP 5711
Connection to PROFIBUS
Amount
1
Transmission speeds
9.6 kbps, 19.2 kbps, 45.45 kbps,
93.75 kbps, 187.5 kbps, 500 kbps,
1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps
Design
9-pin D-sub female connector with screw
locking mechanism
RS-485 (ungrounded within the SELV limits)
Properties
Grounded cable shield
Floating interface signals
Connection to PG/PC
CP end
PG/PC end
Minimum requirement
USB socket type B with locking mechanism
USB socket type A
V 2.0
Plug and play
Electrical specifications of the USB connection
Operating voltage
Rated voltage
5 VDC
Permitted range
4.75 to 5.25 VDC
Properties
Safety extra low voltage (SELV)
complying with IEC 60950-1 / EN 60950-1 /
VDE 0805-1
Direct supply via USB if provided by the
PG/PC; external power supply possible
Current consumption
Maximum
500 mA
Effective power loss
Typical
2.5 W
Electrical specifications when using an external power supply
Operating voltage
Rated voltage
24 VDC
Permitted range
22.8 to 25.2 VDC
Properties Safety extra low voltage (SELV)
complying with IEC 60950-1 / EN 60950-1 /
VDE 0805-1
Current consumption
Maximum
300 mA
Permitted ambient conditions
Operating conditions
Temperature
(EN 60068-2-1+2)
Temperature change, maximum
0 ... +60°C
≤10 K/h
Relative humidity
(EN 60068-2-78)
95%, 16 h at 30°C no condensation
Rapid temperature change
(EN 60068-2-14)
3 h at 0°C, 3 h at 60°C
5 cycles
Storage and transportation conditions Temperature
(EN 60068-2-1+2)
Temperature change, maximum
-40 ... +70°C
≤ 20 K/h
