Chapter 6
Certification
RUGGEDCOM RS900G
Installation Guide
26 EMI and Environmental Type Tests
Agency Standards Comments
FDA/CDRH 21 CFR Chapter I, Sub-chapter J Approved
Section 6.3
EMI and Environmental Type Tests
The RUGGEDCOM RS900G has passed the following EMI and environmental tests.
IEC 61850-3 Type Tests
Test Description Test Levels Severity Levels
Enclosure
Contact
± 8 kV 4IEC 61000-4-2 ESD
Enclosure Air ± 15 kV 4
IEC 61000-4-3 Radiated RFI Enclosure ports 10 V/m 3
Signal ports ± 2 kV x
DC Power Ports ± 4 kV 4
AC Power Ports ± 4 kV 4
IEC 61000-4-4 Burst (Fast Transient)
Earth
Ground Ports
± 4 kV 4
Signal ports ± 4 kV line-to-earth, ± 2 kV line-to-line 4
DC Power Ports ± 2 kV line-to-earth, ± 1 kV line-to-line 3
IEC 61000-4-5 Surge
AC Power Ports ± 4 kV line-to-earth, ± 2 kV line-to-line 4
Signal ports 10 V 3
DC Power Ports 10 V 3
AC Power Ports 10 V 3
IEC 61000-4-6 Induced (Conducted) RFI
Earth
Ground Ports
10 V 3
IEC 61000-4-8 Magnetic Field Enclosure ports 40 A/m continuous, 1000 A/m for 1 s
DC Power Ports 30% for 0.1 s, 100% for
0.02 s, 100% for 0.05 s
IEC 61000-4-29 Voltage Dips and Interrupts
AC Power Ports 30% for 1 period, 60% for 50 periods
IEC 61000-4-11 Voltage Dips and Interrupts AC Power Ports 100% for 5 periods,
100% for 50 periods
Signal ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
DC Power Ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
IEC 61000-4-12 Damped Oscillatory
AC Power Ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
IEC 60255-5 Dielectric Strength Signal ports 0.5 kV (Fail-Safe Relay output)
