Technical Specifications
5.2Failsafe Alarm Relay Specifications
5.2 Failsafe Alarm Relay Specifications
Hazardous Environments
Maximum Switching Voltage Rated
Switching
Current
Isolation
30 VDC 2 A 5.0 kVAC
a
between coil and contacts
1.0 kVAC
a
between contacts
250 VAC 2 A 5.0 kVAC
a
between coil and contacts
1.0 kVAC
a
between contacts
a
50 to 60 Hz for 1 minute
Non-Hazardous Environment
Maximum Switching Voltage Rated
Switching
Current
Isolation
30 VDC 2 A 5.0 kVAC
a
between coil and contacts
1.0 kVAC
a
between contacts
250 VAC 2 A 5.0 kVAC
a
between coil and contacts
1.0 kVAC
a
between contacts
a
50 to 60 Hz for 1 minute
5.3 Supported Networking Standards
The following networking standards are supported by RUGGEDCOM RSG909R:
Standard 10 Mbps
Ports
100 Mbps
Ports
1000 Mbps Ports Notes
IEEE 802.3x • • • Full Duplex Operation
IEEE 802.3z   • 1000Base-LX
IEEE 802.3ab   • 1000Base-Tx
IEEE 802.1D • • • MAC Bridges
IEEE 802.1Q • • • VLAN (Virtual LAN)
IEEE
802.1Q-2005
• • • Multiple Spanning
Tree Protocol (MSTP)
IEEE 802.1w • • • Rapid Spanning
Tree Protocol (RSTP)
IEEE 802.1p • • • Priority Levels
IEEE 802.1x • • • Port-based network
access control
IEEE 802.3 •   10Base-T
IEEE 802.3ad • • • Link aggregation
IEEE 802.3ae   • 10GBase
32
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
