Siemens SIMATIC NET RUGGEDCOM RX1512 User Manual

RUGGEDCOM RX1500
Installation Guide
Chapter 4
Technical Specifications
Gigabit Ethernet (1 Gbps) Optical Specifications 43
Section 4.5.3
Gigabit Ethernet (1 Gbps) Optical Specifications
NOTE
• Maximum segment length is greatly dependent on factors such as fiber quality, and the number
of patches and splices. Consult a Siemens sales associate when determining maximum segment
distances.
• All optical power numbers are listed as dBm averages.
• F51 transceivers are rated for -40 to 85 °C (-40 to 185 °F).
Fixed Gigabit Transceivers
Mode
Connector
Type
Cable
Type (μm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
MM LC 50/125 850 -9 -2.5 -20 0 0.5 11
SM SC 9/125 1310 -10 -3 -20 -3 10 10
SM LC 9/125 1310 -9.5 -3 -21 -3 10 11.5
SM SC 9/125 1310 -5 0 -20 -3 25 15
SM LC 9/125 1310 -7 -3 -24 -3 25 17
SFP Gigabit Transceivers
Mode
Connector
Type
Cable
Type (μm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
50/125 0.5
MM LC
62.5/125
850 -9 -2.5 -20 0
0.3
11
SM LC 9/125 1310 -9.5 -3 -19 -3 10 9.5
SM LC 9/125 1310 -7 -3 -23 -3 25 16
SM LC 9/125 1550 0 5 -23 -3 70 23

Siemens SIMATIC NET RUGGEDCOM RX1512 Specifications

General

Switch Capacity	24 Gbps
MAC Address Table	8K
VLANs	256
Protection Rating	IP30
Ingress Protection	IP30
Layer	Layer 2
Product Type	Industrial Ethernet Switch
Category	Industrial
Jumbo Frames	Up to 9 kB
Power Supply	24 VDC or 110/230 VAC
Operating Temperature	-40°C to +75°C
Mounting	DIN Rail
Redundancy	RSTP, MRP
Management	Web-based, SNMP
Certifications	CE, UL, cUL, FCC
Ports	12 x 10/100/1000Base-T(X) ports, 4 x 100/1000Base-X SFP ports
