Siemens SIMATIC NET S7-1500 User Manual

Guide to the documentation
CP 1543-1
10 Operating Instructions, 12/2019, C79000-G8976-C289-08
Topic
Documentation
Most important contents
Interference-free
installation of
control systems
Function Manual: Interference-free installation
of control systems
(https://support.industry.siemens.com/cs/ww/e
n/view/59193566)
• Basics
• Electromagnetic compatibil-
ity
• Lightning protection
• Housing selection
Cycle and re-
sponse times
Function manual: Cycle and Response Times
(https://support.industry.siemens.com/cs/ww/e
n/view/59193558)
• Basics
• Calculations
CP documentation in the Manual Collection (article number A5E00069051)
The "SIMATIC NET Manual Collection" DVD contains the device manuals and descriptions
of all SIMATIC NET products current at the time it was created. It is updated at regular
intervals.
Version History / Current Downloads for the SIMATIC NET S7 CPs
The "Version History/Current Downloads for SIMATIC NET S7 CPs (Industrial Ethernet)"
document provides information on all CPs available up to now for SIMATIC S7 (Industrial
Ethernet).
The current versions of the document can be found on the Internet:
Link: (https://support.industry.siemens.com/cs/ww/en/view/109474421)

Siemens SIMATIC NET S7-1500 Specifications

General

Product Family	SIMATIC NET
Product Series	S7-1500
Supply voltage	24 V DC
Protection class	IP20
Type	Industrial Ethernet
Transfer rate	10/100/1000 Mbps
Protocols	PROFINET, TCP/IP
Operating temperature	0 °C to 60 °C
Storage Temperature	-40 °C to 70 °C
Interface	RJ45
Product type designation	SIMATIC NET S7-1500
Relative Humidity	5 to 95% (non-condensing)
