Permitted ambient conditions
Weight in g 200
Installation options S7-300 mounting rail
Order numbers
CSM 377 6GK7377-1AA00-0AA0
"Industrial Ethernet TP and Fiber Optic Networks"
manual
6GK1970-1BA10-0AA0
TP Cord RJ45/RJ45 0.5 m 6XV1850-2GE50
IE FC Stripping Tool 6GK1901-1GA00
IE FC blade cassettes 6GK1901-1GB00
IE FC TP standard cable 6XV1840 2AH10
IE FC TP trailing cable 6XV1840-3AH10
IE FC TP marine cable 6XV1840-4AH10
IE FC RJ45 Plug 180 pack of 1 6GK1 901-1BB10-2AA0
IE FC RJ45 Plug 180 pack of 10 6GK1 901-1BB10-2AB0
IE FC RJ45 Plug 180 pack of 50 6GK1 901-1BB10-2AE0
Note
The number of connected switches in󹪞uences the frame delay.
When a frame passes through the CSM 377, it is delayed by the store and forward function of the
switch
- with a 64 byte frame length by approx. 8 µs (at 100 Mbps)
- with a 1500 byte frame length by approx. 125 µs (at 100 Mbps)
This means that the more CSM 377 switches that a frame passes through, the higher the frame
delay will be.
Product properties
3.6 Technical speci󹪝cations
Compact Switch Module CSM 377
18 Operating Instructions, 06/2022, A2B00073499-02

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
