Configuring with Web Based Management
5.3 "Wizard" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 03/2015, C79000-G8976-C267-08
83
Dot1x Supplicant Settings
Introduction
On this Basic Wizard page, you configure the user name and the password with which the
client will be logged on with the RADIUS server.
If you require additional authentication methods, you can configure them after completing the
Basic Wizard with "Security > WLAN > Client Radius Supplicant".
Note
This page is only available in client mode.
Table 1 contains the following columns:
●
Shows the available WLAN interfaces.
●
Enter the user name with which the client will log on with the RADIUS server.
●
Enter the password for the user name selected above. The client is logged on with the
RADIUS server using this combination.
For password assignment, ASCII code 0x20 to 0x7e is used.
●
Dot1x User Password Confirmation
Enter the password again in this input box.
