Configuring with Web Based Management
6.3 "Wizard" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
101
●
If you select the "User defined" entry for the "Antenna Type", enter the antenna gain
manually in the "dBi" unit.
– Antenna Gain 2.4 GHz [dBi]
Enter the antenna gain the antenna has in the 2.4 GHz frequency band.
– Antenna Gain 5 GHz [dBi]Enter the antenna gain the antenna has in the 5 GHz
frequency band.
●
Enter the length of the flexible antenna connecting cable in meters between the device
and the external antenna.
●
Additional Attenuation [dB]
Here, specify the additional attenuation caused, for example, by an additional splitter.
r WLAN interfaces, make sure that you have adequate channel spacing.
Radio Settings
Introduction
On this Basic Wizard page, you specify the configuration for the WLAN interfaces.
This table contains the following columns:
●
Shows the available WLAN interfaces.
●
Enable or disable the WLAN interface. The WLAN interfaces are disabled when the
device is supplied.
