Configuring with Web Based Management
6.3 "Wizard" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
109
Above the tables for the frequency bands, you will find the following check box:
●
Select / Deselect all
– Enabled
If you enable the check box, all channels are selected.
– Disabled
If you deselect the check box, only the first valid channel of the frequency band
remains enabled.
The tables of the frequency bands have the following columns:
●
Radio
Shows the available WLAN interfaces.
●
Radio Mode
Shows the operating mode of the device.
●
Channel number
To specify the valid channels for the required frequency band, select the appropriate
check box for the channel number.
The table displays the permitted channels of the country. Only the valid channels can be
enabled. Invalid channels are grayed out and cannot be enabled.
Note
To specify the channels, the setting "Use Allowed Channels only" must be enabled.
