Transmit power
3
3.1 Frequency band 2.4 GHz
The table below shows the maximum values that are possible for each sending antenna
connector.
• Tolerance ± 2 dBm
Protocol Transmission
speed
Max. transmit power (dBm) Receiver sensi‐
tivity
(dBm)
2.412 GHz 2.442 GHz 2.472 GHz 2.442 GHz
802.11g 6 Mbit/s 20 20 20 -92
12 Mbit/s 20 20 20 -89
54 Mbit/s 20 20 20 -75
802.11n HT20 MCS 0 20 20 20 -90
MCS 7 20 20 20 -73
802.11n HT40 MCS 0 20 20 20 -88
MCS 7 20 20 20 -70
802.11ax HE20 MCS 0 20 20 20 -90
MCS 7 20 20 20 -62
802.11ax HE40 MCS 0 20 20 20 -88
MCS 7 20 20 20 -60
3.2 Frequency band 5 GHz
The table below shows the maximum values that are possible for each sending antenna
connector.
Tolerance ± 2 dBm
Max. conducted power
The value is the summed transmit power of all active antenna connections.
The calculation is made according to the following scheme:
• 1 antenna connection
max. transmit power = Max. conducted power
• 2 antenna connections
max. transmit power + 3 dBm = Max. conducted power
Performance data SCALANCE W700 802.11ax
Reference Manual, 04/2021, C79000-G8976-C620-01 13
