Siemens SIMATIC PP7 User Manual

8-2
PP7, PP17-I, PP17-II Equipment Manual
Release 06/98
0 45.0 76.0 107.0 133.25
Figure 8-2 Text positions for 22.5 mm elements PP7
0 67.0 113.8 160.6 207.4 253.090.4 137.2 184.0 230.8
Figure 8-3 Text positions for keyboards PP17-I and PP17-II
0 72.0 102.8 195.2 226.0 253.0133.6 164.4
Figure 8-4 Text positions for 22.5 mm elements PP17-I
