Siemens SIMATIC PP7 User Manual

C-2
PP7, PP17-I, PP17-II Equipment Manual
Release 06/98
The following functions are available for selection after activating Hardware
T est mode:
Function PP7 display PP17-I and
PP17-I dis -
play
Comment
EPROM TEST CHECK SUM
xxxx
Message concerning
the valid checksum for
the respective firmware
version
DISPL TEST Displays the code of the key
pressed
T erminate the function
with key combination
ESC
+
OK
KEYB. TEST After pressing a key on the
keyboard, the corresponding
LED lights up orange
T erminate the function
with key
or
EEPROM TEST EEPROM OK
SPC2-TEST/
ASPC2-TEST
SPC2 OK ASPC2 OK
DIGIO-TEST DI = xxxx DI = xxxx
DO = xxxx
xxxx = Status of the
digital inputs and out -
puts as hexadecimal
values
KEY-TEST Not imple -
mented
xx Status of the release in -
put
KEYB.ID Not imple -
mented
xxxx Keyboard identifica -
tion:
PP17-I: 2010
PP17-I: 4020
EXT MODUL Not imple -
mented
xxxx xxxx
xxxx xxxx
Extension module iden -
tification
TEST END Terminate Hardware
T est mode
Functions in Hard -
ware T est mode
