Cyclic program execution
3.2 Cycle time
Cycle and response times
Function Manual, 10/2018, A5E03461504-AD
33
Extension due to nesting of higher-priority OBs and/or interrupts
The interruption of a user program at the end of an instruction by a higher-priority OB causes
a certain basic time expenditure. Take account of this basic time expenditure in addition to
the update time of the assigned process image partitions and the execution time of the
contained user program. The following tables contain the typical times for the various
interrupts and error events.
Table 3- 3 Basic time expenditure for an interrupt
S7-1500
1511(F)-1 PN
1511T(F)-1 PN
1511C-1 PN
1512C-1 PN
1513(F)-1 PN
1515(F)-2 PN
1515T(F)-2 PN
1516(F)-3 PN/DP
1516T(F)-3 PN/DP
1517(F)-3 PN/DP
1517T(F)-3 PN/DP
1518(F)-4 PN/DP
1518(F)-4 PN/DP MFP
Hardware inter-
rupt
90 μs 80 μs 20 μs 12 μs
Time-of-day inter-
rupt
90 μs 80 μs 20 μs 12 μs
Time-delay inter-
rupt
90 μs 80 μs 20 μs 12 μs
Cyclic interrupt
90 μs
80 μs
20 μs
12 μs
S7-1500R/H* in RUN-Solo system state
1513R-1 PN
1515R-2 PN
1517H-3 PN
Hardware inter-
rupt
170 μs 140 μs 20 μs
Time-of-day inter-
rupt
170 μs 140 μs 20 μs
Time-delay inter-
rupt
170 μs 140 μs 20 μs
Cyclic interrupt
170 μs
140 μs
20 μs
* Additional information about cycle and response times of R/H CPUs is available in the section "Cycle and response times
of the S7-1500R/H redundant system"
ET 200SP
1510SP(F)-1 PN
1512SP(F)-1 PN
1515SP(F)-PC
Hardware inter-
rupt
90 μs 90 μs 80 μs
Time-of-day inter-
rupt
90 μs 90 μs 80 μs
Time-delay inter-
rupt
90 μs 90 μs 80 μs
Cyclic interrupt
90 μs
90 μs
80 μs
