Siemens SIMATIC S7-300 Module data Getting Started

SM331;AI 8x12 Bit Getting Started Part 2: Voltage and PT100
Getting Started, 11/2006, A5E00264161-02
2-1
Prerequisites
2
2.1 Basics
Basic knowledge
No special knowledge of the field of automation technology is required in order to understand
the Getting Started guide. As the configuration of the analog module is done with the STEP7
software, proficiency in STEP7 would be advantageous.
Further information on STEP7 can be found in the electronic manuals that are supplied with
STEP7.
You will also need to know how to use computers or PC-like equipment (such as
programming devices) with the Windows 95/98/2000/NT or XP operating systems.
Required hardware and software
The scope of delivery of the analog module consists of 2 parts:
● SM331 module
● Front panel connector for convenient connection of the power supply and data cables.
Analog module components
Quantity Item Order no.
1 SM 331, Electrically ISOLATED 8 AI, ALARM DIAGNOSTICS 6ES7331-7KF02-0AB0
1 20-pin FRONT CONNECTOR with spring contacts
Alternatives:
- FRONT CONNECTOR WITH 20-PIN SCREW-TYPE
CONTACTS
- FRONT CONNECTOR MODULE W/ FLAT ROUND CABLE
CONNECTION (TOP connect system cabling)
6ES7392-1BJ00-0AA0
6ES7392-1AJ00-0AA0
6ES7921-3AF00-0AA0
1 SIMATIC S7 SHIELDED SUPPORT ELEMENT 6ES7390-5AA00-0AA0
2 SIMATIC S7, SHIELDED CONNECTION TERMINAL F. 1
CABLE W/ 4...13MM DIAM
6ES7390-5CA00-0AA0

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
