Siemens Simatic S7 Series

32
Review 3
1. The six models of S7-200 are _____ , _____ , _____ ,
_____, _____, and _____ .
2. Which of the following is not available for an CPU 221?
a. Mode Switch
b. Expansion Module
c. Programming Port
d. Status Indicators
3. A CPU 222 can have a maximum of___ expansion
modules and a CPU 224 can have a maximum of ___
expansion modules.
4. A CPU 222 DC/DC/DC has ___ DC inputs and ___ DC
outputs without expansion modules.
5. A CPU 224 DC/DC/DC has ___ DC inputs and ___ DC
outputs without expansion modules.
6. The fourth output of an S7-200 would be labeled
______ .
7. S7-200 can be panel mounted or installed on a ______
rail.
