Review 4
1. Identify the following symbols:
a. ____________
b. ____________
c. ____________
2. Complete the following tables:
AND Function
0
0
1
1
0
1
0
1
a. ___
b. ___
c. ___
d. ___
Input 1
Input 2 Output
OR Function
0
0
1
1
0
1
0
1
e. ___
f. ___
g. ___
h. ___
Input 1
Input 2 Output
3. In the following network, coil Q0.0 will be on when
contact ____ is closed and either contact ____ or
contact ____ or both are closed.
